1) Screw dispensing
1. Equipment technical parameters
Input voltage: three-phase 380V, 50or 60hz
Oscillating power: 150KVA
Max.input power:70KW
Frequency: 30-80KHZ
Cooling water requirement: 0.2MPA, 10L/min
Duty rate: 100%
Host--Extension connection cable length: 2 meters
Special customization :
input voltage 3 × 415V, 3 × 440V 50 or 60HZ
with 500-1.2 meters flexible cable induction ring, easy to move
The main extension soft cable can be customized up to 8 meters long
2. Main applications and features:
Features:
1) With heating current, power and frequency display
2) Input over-current, over-voltage, under-water, light load and other protection.
3) Original Infineon IGBT as inverter component, reliable equipment, durable
4) Main extension soft connection 2 meters, especially suitable for automatic production line or poor environment
5) Car brake pads are quenched
Main application:
1) Screw dispensing
2) Quenching of gears, shafts, etc.
3) Annealing and stamping of stainless steel appliances
4) Copper brazing
3, equipment installation requirements:
1, input power line: 25mm2 soft copper wire, 6mm2 soft copper wire;
2, cooling water requirements: clean water, no impurities, not easy to lead to pipe blockage or structure, inlet water temperature 25-36 ° C ';
3, cooling water source: tap water, simple pump water tank circulating water, using our company's special chiller (see website chiller series).
